40T Hydraulic Extrusion Press Aluminium Die Casting Machine Electric Power Saving

Product Categories

Huzhou Xinke Forging Machine Co., Ltd

Contact Now

Name: 40T Hydraulic Extrusion Press Aluminium Die Casting Machine Electric Power Saving
Brand: XINKE
Price: 10000 USD

Brand Name : XINKE

Certification : CE, ISO9001:2000

Place of Origin : China

MOQ : 1 Unit

Price : USD 10000-200000 Per Unit

Payment Terms : L/C, T/T

Supply Ability : 10 Units Per Months

Delivery Time : 90-180 Working Days

Packaging Details : Wooden case, waterproof cover

Frame : Straight Sided

Drive : Oil Hydraulic

Control : PLC

Application : Rotor of Motors

Contact Now

HY13 40T Hydraulic Press for Aluminum Die Casting

Features:

Application:

Suitable for the process of rotors of motors

Technical Data:

Item		Unit	HY13-40
Range of Motor Rotor die casting			Micro-motor
Mould Clamping Force		KN	400
Ejecting force		KN	100
Pressurization force		KN	/
Cutting force		KN	/
Working pressure of medium		Mpa	25
Stroke of slider		mm	320
Injection piston stroke		mm	150
Opening daylight		kg	520
Aluminum injection capacity		kg	/
Speed of slider	Descend	mm/s	65
	Working	mm/s	10
	Return	mm/s	105
Injection speed	Slow working	mm/s	155
	Quick working	mm/s	600
	Return	mm/s	405
Size of worktable	L.R.	mm	460
	F.B.	mm	400
Motor power		Kw	5.5
Overall size of machine	L.R.	mm	1750
	F.B.	mm	1600
	Height above the floor	mm	2480
Machine weight		kg	2500
